Elevating Leg Rests with Calf Pad for Jazzy and Jet Power Chairs (Set of 2) (FRMASMB3806)
Pride Mobility
LEGREST,ASSY,ELR #12,8.50" X 6" REINFORCED FOOTPLATES,PAIR (FRMASMB3807)
Pride Mobility
Elevating Leg Rest Style 12 with 8-1/2"x6" Footplate for Jazzy and Jet Power Chairs
Monster Scooter Parts
Left Legrest Assembly for the Jazzy Select (FRMASMB3808)
Pride Mobility
Upper Elevating Leg Rest Extension Assembly for Quantum Power Chairs
Pride Mobility
Upper Elevating Leg Rest Extension Assembly for Quantum Power Chairs
KNEE PIVOT, ASSY, ELR STYLE #12, RIGHT
KNEE PIVOT, ASSY, ELR STYLE #12, LEFT
KNEE PIVOT WELDMENT, ELR, LATCH PIN, RIGHT, C-1200-153
KNEE PIVOT WELDMENT, ELR, LATCH PIN, LEFT, C-1200-154
TAPERED PIN, COPPER ALLOY, 3.5"L, RIGHT, D-1000-184
TAPERED PIN, COPPER ALLOY, 3.5"L, LEFT, D-1000-185
SPRING, 0.055"WIRE X 0.50"ID X 0.29"H, CLOCKWISE
SPRING, 0.055"WIRE X 0.50"ID X 0.29"H, COUNTER CLOCKWISE
SLIDE ROD, ELR, RIGHT, B-1000-123
SLIDE ROD, ELR, LEFT, B-1000-223
LATCH, INVESTMENT CAST, ELR/ S/A, C-1010-001
Pride Mobility
SCREW,BHSCS,BLACK ZINC,M6-1.0 X 45MM,(MTS: 51206003) (SCRASBH1076)
ACTUATING HANDLE, ELR LOCKING CAM, B-1000-126
LOCKING CAM MOUNT, ELR, B-1000-125
LOCKING CAM, ELR, A-1000-124
TORSION SPRING, ELR LOCKING CAM, A-1000-128
WASHER, NYLON, 8.1MM ID X 19MM OD X 2MM TH
Pride Mobility
NUT, JAM, PVTP, .3125-24, STL, BZ (DWG 147337) (NUTNJAM1004)
SCREW, SET, M8-1.25 X 12MM, CUP POINT
SCREW, SET, M6-1.0 X 10MM, CUP POINT
SCREW, SET, BLACK ZINC, M4-.7 X 4MM
SCREW, BHSCS, M8-1.25 X 40MM
LEGREST, ELR #11 UPPER TUBE, 14"-17" & 17"-20", LEFT/RIGHT
BUSHING, NYLON, 0.34"ID X 0.90"OD X 1.0"TH
FRAME, UPPER EXTENSION TUBE, LONG, 10.60"L, ELR STYLE #11
Pride Mobility
SCREW,BHSCS,BLACK ZINC,5/16-18 X 1.50",GRADE 5 (SCRASBH1020)
NUT, NYLOCK, 5/16-18, JAM
Monster Scooter Parts
Pride Mobility
8-1/2"X6" Footplate & Lower Extension Weldment for Jazzy & Quantum Power Chairs
Pride Mobility
8-1/2"X6" Footplate & Lower Extension Weldment for Jazzy & Quantum Power Chairs
Pride Mobility
FOOTPLATE,8.50" X 6" REINFORCED CAST,RIGHT,D-1000-180 (DWR1000D180)
Monster Scooter Parts
Left Footplate for the Jazzy 600 (DWR1000D179)
Monster Scooter Parts
Lower Legrest Assembly for the Jazzy 600 (FRMASMB4856)
LEGREST EXTENSION WELDMENT, LOWER, CHROME, 14"-17"
Pride Mobility
BUMPER,END CAP,7/8"OD,FITS 16 GAUGE TUBING (PROBUMP1010)
CAP, END, BLACK, PLASTIC, 19MM OD, FITS 15MM ID TUBING, ROUND, B-9940-014
Monster Scooter Parts
Calf Pad Assembly with Mounting Bracket for Jazzy and Jet Power Chairs (FRMASMB5732)
Monster Scooter Parts
Calf Pad Mounting Bracket for the Quantum Q6 Edge (FRMASMB5731)
CALF PAD MOUNTING CLAMP, COMPACT, C-1000-346
CALF PAD MOUNTING BRACKET, COMPACT, C-1000-345
BUSHING, FLANGE, 25.6MM ID X 27MM OD X 6MM TH X 33.3MM FOD X 1MM FT
