BATTERY, CLIP, HOLD-DOWN, D-8500-035-DETAIL 3
SEAT POST WELDMENT, LOWER, C-8500-022
SCREW, HHCS, ZINC, 5/16-18 X 1.75", GRADE 5
Monster Scooter Parts
3/8" x 3-3/8" Quick Release Seat Pin for Pride and Jazzy Rear Basket Assemblies
WELDMENT, STEERING ROD, WRANGLER, B-8500-013
Monster Scooter Parts
Swing Arm Nut for the Jazzy 1170 XL Plus (NUTNYLK1006)
BUSHING, BRONZE OILITE, 1/2"IDX3/4"ODX1 1/4"LX 1/8FL
LEFT AXLE BLOCK WELDMENT, WRANGLER, C-8500-057
BOLT, SHOULDER, 1/2" X 3.00"
RIGHT AXLE BLOCK WELDMENT, WRANGLER, C-8500-067
BALL JOINT, 3/8"-24 LH THREAD, TIE ROD
Pride Mobility
WASHER, HEAVY SPRING LOCK, .375 ID X .688 OD X .115 THK, ASME B18.21.1, STEEL, BZ (WASLOCK1014)
TIE ROD, D-8500-069
NUT, HEX, ZINC, 3/8"-24, LH
SCREW, SHCS, BLACK ZINC, 3/8-24X2.25"
BALL JOINT, 3/8"-24 RH THREAD, LINKAGE
Monster Scooter Parts
Headset Steering Bearing Kit for Go-Go and Pride Mobility Scooters (HDWASMB1000)
Monster Scooter Parts
Bumper Cap Black for the Pride Wrangler (PMV600) (PROECAP1000)
SCREW, HHCS, BLACK ZINC, 5/16-18 X 2 1/4", G5
